Omschrijving
VISHAY - IHLP5050EZER2R2M01 - Power Inductor (SMD), 2.2 µH, 20 A, Shielded, 32 A, IHLP-5050EZ-01, 13.2mm x 12.9mm x 5mm
- Inductance: 2.2µH
- RMS Current (Irms): 20A
- Inductor Construction: Shielded
- Saturation Current (Isat): 32A
- Product Range: IHLP-5050EZ-01 Series
- Power Inductor Case: 13.2mm x 12.9mm x 5mm
- DC Resistance Max: 0.0055ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (27-Jun-2018)
- External Depth: 12.9mm
- External Length / Height: 5mm
- External Width: 13.2mm
- Inductor Type: High Current
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Resonant Frequency: 100kHz
