VISHAY - IHTH1125MZEBR47M5A - Inductor, IHTH-1125MZ-5A Series, 470 nH, 105 A, 80 A, 300 µohm, ± 20%
- Product Range: IHTH-1125MZ-5A Series
- Inductance: 470nH
- RMS Current (Irms): 105A
- Saturation Current (Isat): 80A
- DC Resistance Max: 300µohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (27-Jun-2018)
- Body Diameter: 29.95mm
- Core Material: Iron Powder
- DC Current Rating: 73A
- External Length / Height: 12.7mm
- Inductance Measurement Frequency: 100kHz
- Inductor Case Style: Radial Leaded
- Inductor Type: High Current
- Lead Diameter: 2.71mm
- Lead Length: 4.19mm
- Lead Spacing: 14.45mm
- No. of Pins: 2Pins
- Operating Temperature Max: 155°C
- Operating Temperature Min: -55°C
- Resonant Frequency: 1MHz
