IM02GR Relay, Signal, DPDT, 250VAC, 220VDC, 2A AXICOM - Te Connectivity

AXICOM - TE CONNECTIVITYSKU:IM02GR Bestelcode:1175068

Prijs:
Actie prijs€7,01

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (15297 units)

Omschrijving

AXICOM - TE CONNECTIVITY - IM02GR - Signal Relay, MSL3, 4.5 VDC, DPDT, 2 A, IM, Surface Mount, Non Latching

  • Coil Voltage: 4.5VDC
  • Contact Configuration: DPDT
  • Contact Current: 2A
  • Product Range: IM Series
  • Relay Mounting: SMD
  • Coil Type: Non Latching
  • Relay Terminals: Solder
  • Contact Voltage VAC: 250V
  • Contact Voltage VDC: 220V
  • Contact Material: Palladium Ruthenium
  • Coil Resistance: 145ohm
  • SVHC: No SVHC (27-Jun-2018)
  • Approval Bodies: CECC, EN, IEC
  • Approval Category: UL Recognised
  • Coil Power Continuous: 140mW
  • Coil Voltage VDC Nom: 4.5V
  • Contact Current AC Max: 2A
  • Contact Current DC Max: 2A
  • Contact Current Max: 2A
  • Contact Voltage AC Max: 250V
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Max: 220V
  • Contact Voltage DC Nom: 220V
  • DC Coil Power: 200mW
  • Dielectric Voltage Coil to Contact: 1800VAC
  • Dielectric Voltage Contact to Contact: 1000VAC
  • External Depth: 10mm
  • External Height: 5.65mm
  • External Length / Height: 5.65mm
  • External Width: 6mm
  • Must Actuate Voltage: 3.38V
  • Must Release Voltage: 0.45V
  • No. of Pins: 8Pins
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -40°C
  • VSWR: 1.49
