XP POWER - IP4805S - Isolated Through Hole DC/DC Converter, Regulated, ITE, 4:1, 3 W, 2 Output, 5 V, 300 mA
- DC/DC CONVERTER, 3W, 4: 1 I/P5V O/P
- No. of Outputs: 2 Output
- Output Power Max: 3W
- Output Voltage - Output 1: 5V
- Output Current - Output 1: 300mA
- Output Voltage - Output 2: -5V
- Output Current - Output 2: 300mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: IP Series
- Input Voltage DC Min: 18V
- Input Voltage DC Max: 75V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: SIP
- DC / DC Converter Mounting: Through Hole
- Width: 9.2mm
- Height: 11.1mm
- Depth: 21.85mm
- SVHC: No SVHC (15-Jan-2018)
- Isolation Voltage: 1.6kV
- No. of Outputs: 2Outputs
- Power Rating: 3W
- Supply Voltage: 48V
