XP POWER - IW2415SA - Isolated Through Hole DC/DC Converter, Regulated, ITE, 2:1, 1 W, 1 Output, 15 V, 67 mA
- CONVERTER, DC/DC, 2: 1I/P, 1W, 15V
- No. of Outputs: 1 Output
- Output Power Max: 1W
- Output Voltage - Output 1: 15V
- Output Current - Output 1: 67mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: -
- Input Voltage DC Min: 18V
- Input Voltage DC Max: 36V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: SIP
- DC / DC Converter Mounting: Through Hole
- Width: 9.2mm
- Height: 11.1mm
- Depth: 21.85mm
- SVHC: No SVHC (15-Jan-2018)
- Efficiency: 72%
- External Depth: 11.1mm
- External Length / Height: 21.85mm
- External Width: 9.2mm
- Isolation Voltage: 1kV
- Line Regulation: 0.5%
- Load Regulation: 1%
- No. of Outputs: 1Outputs
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Output Ripple Voltage pk-pk: 80mV
- Power Rating: 1W
- Supply Voltage: 24V
