IXFK48N50 MOSFET, N, TO-264 IXYS Semiconductor

IXYS SEMICONDUCTORSKU:IXFK48N50 Bestelcode:9359176

Prijs:
Actie prijs€32,70

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (315 units)

Documenten en downloads

Omschrijving

IXYS SEMICONDUCTOR - IXFK48N50 - Power MOSFET, N Channel, 500 V, 48 A, 0.1 ohm, TO-264, Through Hole

  • Transistor Polarity: N Channel
  • Continuous Drain Current Id: 48A
  • Drain Source Voltage Vds: 500V
  • On Resistance Rds(on): 0.1ohm
  • Rds(on) Test Voltage Vgs: 10V
  • Threshold Voltage Vgs: 4V
  • Power Dissipation Pd: 500W
  • Transistor Case Style: TO-264
  • No. of Pins: 3Pins
  • Operating Temperature Max: 150°C
  • Product Range: -
  • Automotive Qualification Standard: -
  • MSL: -
  • SVHC: No SVHC (12-Jan-2017)
  • Current Id Max: 48A
  • Current Temperature: 25°C
  • Full Power Rating Temperature: 25°C
  • No. of Transistors: 1
  • On State Resistance Max: 100mohm
  • Operating Temperature Min: -55°C
  • Operating Temperature Range: -55°C to +150°C
  • Pulse Current Idm: 192A
  • Voltage Vds Typ: 500V
  • Voltage Vgs Max: 4V
  • Voltage Vgs Rds on Measurement: 10V
  • Voltage Vgs th Max: 4V
