XP POWER - JCD0505D05 - Isolated Through Hole DC/DC Converter, 2:1 Input, ITE, 2:1, 5 W, 2 Output, 5 V, 500 mA
- No. of Outputs: 2 Output
- Output Power Max: 5W
- Output Voltage - Output 1: 5V
- Output Current - Output 1: 500mA
- Output Voltage - Output 2: -5V
- Output Current - Output 2: 500mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: JCD Series
- Input Voltage DC Min: 4.5V
- Input Voltage DC Max: 9V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 20.32mm
- Height: 10.4mm
- Depth: 31.75mm
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: EN
- Isolation Voltage: 1.6kV
- No. of Outputs: 2Outputs
- Power Rating: 5W
- Supply Voltage: 5V
