JCD0548S09 DC/DC Converter, 5W, 9V, Dip-24 XP Power

XP POWERSKU:JCD0548S09 Bestelcode:2065250

Prijs:
Actie prijs€25,47

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Uitverkocht

Documenten en downloads

Omschrijving

XP POWER - JCD0548S09 - Isolated Through Hole DC/DC Converter, 2:1 Input, ITE, 2:1, 5 W, 1 Output, 9 V, 555 mA

  • No. of Outputs: 1 Output
  • Output Power Max: 5W
  • Output Voltage - Output 1: 9V
  • Output Current - Output 1: 555mA
  • Output Voltage - Output 2: -
  • Output Current - Output 2: -
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: JCD Series
  • Input Voltage DC Min: 36V
  • Input Voltage DC Max: 72V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 20.32mm
  • Height: 10.4mm
  • Depth: 31.75mm
  • SVHC: No SVHC (15-Jan-2018)
  • Approval Bodies: EN
  • Isolation Voltage: 1.6kV
  • No. of Outputs: 1Outputs
  • Power Rating: 5W
  • Supply Voltage: 48V
