XP POWER - JCP4024D12 - Isolated Through Hole DC/DC Converter, Metal Case, ITE, 2:1, 40 W, 2 Output, 12 V, 1.8 A
- No. of Outputs: 2 Output
- Output Power Max: 40W
- Output Voltage - Output 1: 12V
- Output Current - Output 1: 1.8A
- Output Voltage - Output 2: -12V
- Output Current - Output 2: 1.8A
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: -
- Input Voltage DC Min: 18V
- Input Voltage DC Max: 36V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 50.8mm
- Height: 10.2mm
- Depth: 50.8mm
- SVHC: No SVHC (15-Jan-2018)
- Efficiency: 87%
- External Depth: 10.2mm
- External Length / Height: 50.8mm
- External Width: 29.2mm
- Isolation Voltage: 1.5kV
- No. of Outputs: 2Outputs
- Off Load Current: 100mA
- Operating Temperature Max: 100°C
- Operating Temperature Min: -40°C
- Output Current - Max: 1.8A
- Output Ripple Voltage pk-pk: 75mV
- Output Voltage +: 12V
- Output Voltage -: 12V
- Power Rating: 40W
- Supply Voltage: 24V
