LC1D32BL Contactor, 15KW, 24Vdc Schneider Electric

SCHNEIDER ELECTRICSKU:LC1D32BL Bestelcode:3622575

Prijs:
Actie prijs€260,81

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (10 units)

Documenten en downloads

Omschrijving

SCHNEIDER ELECTRIC - LC1D32BL - Contactor, LC1D, 32 A, DIN Rail, 24 V, DPDT, 3 Pole, 15 kW

  • Load Current Inductive: 32A
  • Relay Mounting: DIN Rail
  • Operating Voltage: 24V
  • Contact Configuration: DPDT
  • No. of Poles: 3 Pole
  • Switching Power AC3: 15kW
  • Switching Current AC1: 50A
  • Coil Voltage VAC Nom: -
  • Coil Voltage VDC Nom: 24V
  • Switching Power AC1: 5hp
  • Load Current Resistive: 50A
  • Switching Current AC3: 32A
  • Product Range: TeSys D Series
  • SVHC: No SVHC (15-Jan-2018)
  • AC Coil Power: 5.4VA
  • Breaking Capacity Current AC: 550A
  • Coil Operating Lower Percent Limit: 70%
  • Coil Operating Upper Percent Limit: 125%
  • Coil Type: DC
  • Contact Current DC Max: 32A
  • Contact Current Max: 50A
  • Contact Voltage AC Nom: 600V
  • Contact Voltage DC Max: 24V
  • DC Coil Power: 5.4W
  • External Depth: 101mm
  • External Length / Height: 85mm
  • External Width: 45mm
  • IP / NEMA Rating: IP2X
  • Insulation Voltage: 690V
  • Main Contact Current AC1 Max: 50A
  • Main Contact Current AC3 Max: 32A
  • Nom Operating Power: 2.4W
  • Operating Temperature Max: 60°C
  • Relay Type: Contactor
  • Standard: EN60947 - 1
  • Termination Type: Screw
