LPV-20-24 LED Driver, AC-DC, CV, 0.84A, 24V Mean Well

MEAN WELLSKU:LPV-20-24 Bestelcode:2114228

Prijs:
Actie prijs€19,34

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (41 units)

Documenten en downloads

Omschrijving

MEAN WELL - LPV-20-24 - LED Driver, ITE, 20.2 W, 24 V, 840 mA, Constant Voltage, 90 V

  • Output Power Max: 20.2W
  • Output Voltage Max: 24V
  • Output Current: 840mA
  • LED Driver Mode: Constant Voltage
  • Input Voltage Min: 90V
  • Input Voltage Max: 264V
  • Product Range: LPV-20 Series
  • SVHC: No SVHC (12-Jan-2017)
  • Approval Bodies: CE
  • Current Rating: 0.84A
  • Depth: 26mm
  • Dimming Control Type: PWM
  • Efficiency: 83%
  • Height: 26mm
  • IP Rating: IP67
  • Length: 118mm
  • No. of Channels: 1Channels
  • No. of Outputs: 1Outputs
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -30°C
  • Operating Temperature Range: -30°C to +70°C
  • Output Power: 20.2W
  • Output Voltage: 24V
  • Power Rating: 20W
  • Power Supply Mounting: Chassis
  • Power Supply Output Type: Adjustable, Fixed
  • Power Supply Type: External Power Supply
  • Supply Voltage: 230V
  • Supply Voltage AC Max: 264V
  • Supply Voltage AC Min: 90V
  • Termination Style: Flying Leads
  • Width: 35mm
