M80-8400645 Socket, Vertical, 1ROW, 6Way Harwin

HARWINSKU:M80-8400645 Bestelcode:9789502

Prijs:
Actie prijs€7,27

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (136 units)

Documenten en downloads

Omschrijving

HARWIN - M80-8400645 - PCB Receptacle, Wire-to-Board, 2 mm, 1 Rows, 6 Contacts, Through Hole Mount, Datamate L-Tek M80

  • Pitch Spacing: 2mm
  • No. of Contacts: 6Contacts
  • Gender: Receptacle
  • Product Range: Datamate L-Tek M80 Series
  • Contact Termination Type: Through Hole
  • No. of Rows: 1Rows
  • Contact Plating: Gold Plated Contacts
  • Contact Material: Phosphor Bronze
  • SVHC: Lead (15-Jan-2019)
  • Contact Resistance: 25mohm
  • Contact Termination: Through Hole Vertical
  • Current Rating: 3.3A
  • Flammability Rating: UL94V-0
  • Insulation Resistance: 100mohm
  • Lead Spacing: 2mm
  • Material: Glass Filled Thermoplastic
  • No. of Mating Cycles: 500
  • Proof Voltage: 360V
  • Termination Method: Solder
  • Wire Size AWG Max: 22AWG
  • Wire Size AWG Min: 28AWG
  • Working Voltage: 120V
