M80-8501042 Socket, Double Row, Pcb, 10WAY Harwin

HARWINSKU:M80-8501042 Bestelcode:1568659

Prijs:
Actie prijs€9,46

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (147 units)

Documenten en downloads

Omschrijving

HARWIN - M80-8501042 - PCB Receptacle, Board-to-Board, Wire-to-Board, 2 mm, 2 Rows, 10 Contacts, Through Hole Mount

  • Pitch Spacing: 2mm
  • No. of Contacts: 10Contacts
  • Gender: Receptacle
  • Product Range: Datamate L-Tek M80 Series
  • Contact Termination Type: Through Hole
  • No. of Rows: 2Rows
  • Contact Plating: Gold Plated Contacts
  • Contact Material: Beryllium Copper
  • SVHC: Lead (15-Jan-2019)
  • Colour: Black
  • Contact Resistance: 25mohm
  • Contact Termination: Solder
  • Flammability Rating: UL94V-0
  • Insulation Resistance: 100Mohm
  • Lead Spacing: 2mm
  • Material: Glass-Filled Polyamide 46
  • No. of Mating Cycles: 500
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -55°C
  • Row Pitch: 2mm
  • Termination Method: Solder
  • Working Voltage: 120V
