Omschrijving
VISHAY - MAL205956479E3 - Electrolytic Capacitor, Long Life, 47 µF, 400 V, ± 20%, Quick Connect, Snap-In, 10000 hours @ 105°C
- Capacitance: 47µF
- Voltage Rating: 400V
- Product Range: 059 PLL-SI Series
- Lifetime @ Temperature: 10000 hours @ 105°C
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Quick Connect, Snap-In
- Diameter: 22mm
- Lead Spacing: 10mm
- Operating Temperature Min: -25°C
- Operating Temperature Max: 105°C
- Height: 30mm
- ESR: 4.26ohm
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- AC Ripple Current @ 100Hz: 0.3A
- Capacitance Tolerance ±: ± 20%
- Capacitor Mounting: Through Hole
- Climatic Category: 40/105/56
- ESR Frequency: 100Hz
- ESR Temperature: 20°C
- External Length / Height: 30mm
- Impedance: 3490mohm
- Impedance Frequency: 10kHz
- Impedance Temperature: 20°C
- Leakage Current: 766.3µA
- No. of Pins: 2Pins
- Operating Life Temperature: 40°C
- Operating Temperature Range: -40°C to +105°C
- Operating life Time: 10000h
- PCB Hole Diameter: 2mm
- Ripple Current AC: 0.3A
- Ripple Current Frequency: 100Hz
- Ripple Current Temperature: 105°C
- Tolerance +: 0.2%
- Tolerance -: 0.2%
- Voltage Rating DC Max: 400V
