MAL210118153E3 Cap, 15000µF, 63V, Alu Elec, Screw Vishay

VISHAYSKU:MAL210118153E3 Bestelcode:8820821

Prijs:
Actie prijs€54,84

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (258 units)

Documenten en downloads

Omschrijving

VISHAY - MAL210118153E3 - Electrolytic Capacitor, Screw, 15000 µF, 63 V, ± 20%, Screw, 10000 hours @ 85°C

  • Capacitance: 15000µF
  • Voltage Rating: 63V
  • Product Range: 101 PHR-ST Series
  • Lifetime @ Temperature: 10000 hours @ 85°C
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Screw
  • Diameter: 35mm
  • Lead Spacing: 12.8mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Height: 105mm
  • ESR: 0.016ohm
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (27-Jun-2018)
  • AC Ripple Current @ 100Hz: 11A
  • AC Ripple Current @ 20kHz: 11A
  • Capacitance Tolerance ±: ± 20%
  • Capacitor Mounting: Panel
  • Climatic Category: 40/085/86
  • External Length / Height: 105mm
  • Leakage Current: 1.89mA
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +85°C
  • Operating life Time: 10000h
  • Ripple Current AC: 11A
  • Ripple Current Frequency: 100Hz
  • Ripple Current Temperature: 85°C
  • Tolerance +: 0.2%
  • Tolerance -: 0.2%
  • Voltage Rating DC Max: 63V
  • Voltage Rating V DC: 63V
