MAL215370109E3 Cap, 10µF, 35V, Radial, SMD Vishay

VISHAYSKU:MAL215370109E3 Bestelcode:1834254

Prijs:
Actie prijs€1,07

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (8061 units)

Documenten en downloads

Omschrijving

VISHAY - MAL215370109E3 - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 10 µF, 35 V, 4 ohm, 1000 hours @ 105°C

  • AE Capacitor Case: Radial Can - SMD
  • Capacitance: 10µF
  • Voltage Rating: 35V
  • ESR: 4ohm
  • Product Range: 153 CRV Series
  • Lifetime @ Temperature: 1000 hours @ 105°C
  • Operating Temperature Min: -55°C
  • Operating Temperature Max: 105°C
  • Ripple Current AC: 23mA
  • Diameter: 5mm
  • Height: 5.3mm
  • Automotive Qualification Standard: -
  • MSL: -
  • SVHC: No SVHC (27-Jun-2018)
  • AC Ripple Current @ 100Hz: 23mA
  • Capacitance Tolerance: ± 20%
  • Capacitance Tolerance ±: ± 20%
  • Capacitor Case Style: Radial Can - SMD
  • Capacitor Mounting: SMD
  • Capacitor Terminals: SMD
  • ESR Frequency: 100kHz
  • External Depth: 5mm
  • External Length / Height: 5.3mm
  • External Width: 5mm
  • Leakage Current: 3.5µA
  • No. of Pins: 2Pins
  • Operating Temperature Range: -55°C to +105°C
  • Operating life Time: 2000h
  • Reel Quantity: 1000
  • Ripple Current Frequency: 120Hz
  • Ripple Current Temperature: 105°C
  • Tolerance +: 0.2%
  • Tolerance -: 0.2%
  • Voltage Rating DC Max: 35V
  • Voltage Rating V DC: 35V
