MULTICOMP PRO - MCCB1A476M2DCB - Tantalum Capacitor, 47 µF, 10 V, ± 20%, PC Pin, 5.1 mm, 1.7 ohm
- Capacitance: 47µF
- Voltage Rating: 10V
- Product Range: MCCB Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Lead Spacing: 5.1mm
- Operating Temperature Min: -55°C
- Operating Temperature Max: 125°C
- ESR: 1.7ohm
- SVHC: No SVHC (15-Jan-2019)
- Body Diameter: 7.5mm
- Capacitance Tolerance ±: ± 20%
- External Depth: 6.5mm
- External Length / Height: 11mm
- External Width: 6.5mm
- Height: 11mm
- Impedance: 1.7ohm
- Impedance Frequency: 100kHz
- Impedance Temperature: 20°C
- Lead Diameter: 0.5mm
- Leakage Current: 3.7µA
- No. of Pins: 2Pins
- Operating Temperature Range: -55°C to +125°C
- Tolerance +: 20%
- Tolerance -: 20%
- Voltage Rating V DC: 10V
