mF-R075 Fuse, PTC, 0.75A, 90V, Radial Bourns

BOURNSSKU:MF-R075 Bestelcode:2291870

Prijs:
Actie prijs€0,65

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (3317 units)

Documenten en downloads

Omschrijving

BOURNS - MF-R075 - Resettable Fuse, PPTC, MF-R, 60 VDC, 750 mA, 1.5 A, 6.3 s, Round

  • Thermistor Mounting: Through Hole
  • Product Range: MF-R Series
  • Holding Current: 750mA
  • Tripping Current: 1.5A
  • Voltage Rating: 60V
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2018)
  • Approval Bodies: CSA, TUV, UL
  • Body Diameter: 10.4mm
  • Carrying Current Max: 90A
  • Case Material: Epoxy polymer
  • Current Max: 40A
  • External Depth: 3.1mm
  • External Length / Height: 15.2mm
  • External Width: 10.4mm
  • Flammability Rating: UL94V-0
  • Holding Current Max Ih: 0.75A
  • Initial Resistance Max: 0.75ohm
  • Initial Resistance Min: 0.18ohm
  • Lead Diameter: 0.51mm
  • Lead Length: 7.6mm
  • Lead Spacing: 5.1mm
  • Operating Voltage: 60V
  • PTC Fuse Case Style: Radial Leaded
  • Pitch Max: 5.8mm
  • Pitch Min: 4.3mm
  • Surface Tripped Temperature Max: 125°C
  • Thermistor Type: PTC Resettable Fuse
