Omschrijving
SEPA - MFB40H12 - DC Axial Fan, 12 V, Square, 40 mm, 10 mm, Ball Bearing, 6.06 CFM
- Supply Voltage: 12V
- Current Type: DC
- Fan Frame Size: 40mm
- External Depth: 10mm
- Noise Rating: 25dBA
- Flow Rate - Imperial: 6.06cu.ft/min
- Flow Rate - Metric: 10.3m³/h
- Bearing Type: Ball
- Power Connection Type: 2 Lead Wires
- Current Rating: 60mA
- Product Range: MFB40H Series
- Power Rating: -
- IP Rating: -
- SVHC: No SVHC (15-Jan-2019)
- Blade Diameter: 37mm
- External Height: 40mm
- External Width: 40mm
- Fixing Centres: 32mm
- Frame Dimensions: 40mm x 40mm x 10mm
- Input Voltage Max: 13.5VDC
- Input Voltage Min: 10.5VDC
- Lead Length: 300mm
- Operating Temperature Max: 60°C
- Operating Temperature Min: -10°C
- Pressure Max: 28Pa
- Supply Voltage DC Max: 13.5V
- Supply Voltage DC Min: 10.5V
