PHOENIX CONTACT - MFKDSP/ 2-5,08 - Wire-To-Board Terminal Block, 5.08 mm, 2 Ways, 22 AWG, 18 AWG, 1.5 mm², Push In
- Pitch Spacing: 5.08mm
- No. of Positions: 2Ways
- Wire Size AWG Min: 22AWG
- Wire Size AWG Max: 18AWG
- Conductor Area CSA: 1.5mm²
- Wire Connection Method: Push In
- Rated Current: 12A
- Rated Voltage: 250V
- Block Orientation: Through Hole 45°
- Product Range: MFKDSP Series
- Connector Mounting: PCB Mount
- Connector Type: Terminal Block, PCB
- Contact Material: Copper
- Contact Plating: Tin Plated Contacts
- Voltage Rating VAC: 250V
- Wire Area Size Max: 1.5mm²
- Wire Area Size Min: 0.2mm²
