MJL3281AG Transistor, NPN, TO-264 ONSEMI

ONSEMISKU:MJL3281AG Bestelcode:1172585

Prijs:
Actie prijs€8,12

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (301 units)

Documenten en downloads

Omschrijving

ONSEMI - MJL3281AG - Bipolar (BJT) Single Transistor, Audio, NPN, 260 V, 15 A, 200 W, TO-264, Through Hole

  • Transistor Polarity: NPN
  • Collector Emitter Voltage V(br)ceo: 260V
  • Transition Frequency ft: 30MHz
  • Power Dissipation Pd: 200W
  • DC Collector Current: 15A
  • DC Current Gain hFE: 175hFE
  • Transistor Case Style: TO-264
  • No. of Pins: 3Pins
  • Operating Temperature Max: 150°C
  • Product Range: -
  • Automotive Qualification Standard: -
  • MSL: -
  • SVHC: Lead (27-Jun-2018)
  • Av Current Ic: 15A
  • Collector Emitter Saturation Voltage Vce(on): 3V
  • Continuous Collector Current Ic Max: 15A
  • Current Ic Continuous a Max: 15A
  • Current Ic hFE: 5A
  • Device Marking: MJL3281A
  • Full Power Rating Temperature: 25°C
  • Gain Bandwidth ft Min: 30MHz
  • Gain Bandwidth ft Typ: 30MHz
  • Hfe Min: 75
  • No. of Transistors: 1
  • Operating Temperature Min: -65°C
  • Operating Temperature Range: -65°C to +150°C
  • Power Dissipation Ptot Max: 200W
  • Pulsed Current Icm: 25A
  • Termination Type: Through Hole
  • Voltage Vcbo: 260V
