Mp-13-10F-1 58 TGN/Z RF Coaxial, BNC, Straight Plug, 50ohm multicomp Pro

MULTICOMP PROSKU:MP-13-10F-1 58 TGN/Z Bestelcode:1169602

Prijs:
Actie prijs€232,36

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (15 units)

Documenten en downloads

Omschrijving

MULTICOMP PRO - MP-13-10F-1 58 TGN/Z - RF / Coaxial Connector, BNC Coaxial, Straight Plug, Crimp, 50 ohm, RG58, Brass

  • Connector Type: BNC Coaxial
  • Connector Body Style: Straight Plug
  • Coaxial Termination: Crimp
  • Impedance: 50ohm
  • Coaxial Cable Types: RG58
  • Contact Material: Brass
  • Contact Plating: Gold Plated Contacts
  • Frequency Max: 11GHz
  • Connector Mounting: Cable Mount
  • Product Range: -
  • SVHC: Lead (15-Jan-2019)
  • Approval Bodies: MIL Spec
  • Body Plating: Nickel
  • Cable Diameter Max: 5mm
  • Coaxial Type: RG58
  • Connector Mounting Orientation: Cable
  • Contact Resistance: 1.5mohm
  • DC Current Max: 1A
  • Material: Brass
  • Operating Frequency Max: 11GHz
  • Operating Temperature Max: 165°C
  • Operating Temperature Min: -65°C
  • Proof Voltage: 2kV
  • Termination Method: Crimp
  • VSWR: 1.35
  • Working Voltage: 500V
