Mpg 106 D Switch, On-On, SPDT Knitter-Switch

KNITTER-SWITCHSKU:MPG 106 D Bestelcode:8546886

Prijs:
Actie prijs€25,86

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (160 units)

Documenten en downloads

Omschrijving

KNITTER-SWITCH - MPG 106 D - Pushbutton Switch, MPG, 11.8 mm, SPDT, On-On, Round, Black

  • Switch Operation: On-On
  • Contact Configuration: SPDT
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Nom: 30V
  • Contact Current Max: 6A
  • Switch Terminals: Solder Lug
  • Product Range: MPG Series
  • SVHC: No SVHC (15-Jan-2018)
  • Actuation Type: Plunger
  • Actuator / Cap Colour: Black
  • Bush Diameter: 12mm
  • Contact Current @ Contact Voltage AC Max: 3A
  • Contact Current AC Max: 6A
  • Contact Current DC Max: 4A
  • Contact Resistance: 10mohm
  • Contact Resistance Max: 10mohm
  • Contact Voltage VAC: 125V
  • Contact Voltage VDC: 28V
  • External Depth: 8mm
  • External Length / Height: 30.7mm
  • External Width: 13mm
  • Illumination Colour: Non-illuminated
  • Insulation Resistance: 1000Mohm
  • No. of Mechanical Operations: 30000
  • Operating Temperature Max: 140°C
  • Operating Temperature Min: 45°C
  • Panel Cutout Diameter: 11.8mm
  • Pushbutton Actuator Style: Round
  • Pushbutton Switch Type: Standard
  • Switch Mounting: Panel
  • Thread Size: 15/32-32
