MR/P/440/25/C Cap, 25µF, 440VAC, 10%, PP, Can, Panel LCR Components

LCR COMPONENTSSKU:MR/P/440/25/C Bestelcode:1190559

Prijs:
Actie prijs€11,59

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (371 units)

Documenten en downloads

Omschrijving

LCR COMPONENTS - MR/P/440/25/C - Motor Run Capacitor, Metallized PP, Can, 25 µF, ± 10%, Stud Mount - M8, 440 V

  • Capacitance: 25µF
  • Product Range: MR/P/440 Series
  • Voltage Rating: 440VAC
  • Capacitor Terminals: Quick Connect, Snap-In
  • Capacitance Tolerance: ± 10%
  • dv/dt Rating: -
  • Capacitor Dielectric Type: PP (Polypropylene)
  • Capacitor Case Style: Can
  • Height: 98mm
  • Diameter: 50mm
  • Stud Size - Metric: M8
  • Operating Temperature Min: -25°C
  • Operating Temperature Max: 85°C
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2019)
  • Body Diameter: 50mm
  • Capacitance Tolerance ±: ± 10%
  • Capacitor Application: Motor Start / Motor Run
  • Capacitor Mounting: Panel
  • External Length / Height: 98mm
  • Lead Length: 6.35mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -25°C to +85°C
  • Power Factor: 0.001
  • Power Factor Frequency: 50kHz
  • Thread Size: M8
  • Tolerance +: 10%
  • Tolerance -: 10%
  • Voltage Rating VAC: 440V
