COILCRAFT - MSS1038-683MLC - Power Inductor (SMD), 68 µH, 1.75 A, Shielded, 1.32 A, MSS1038, 10.2mm x 10mm x 3.8mm
- Inductance: 68µH
- RMS Current (Irms): 1.75A
- Inductor Construction: Shielded
- Saturation Current (Isat): 1.32A
- Product Range: MSS1038 Series
- Power Inductor Case: 10.2mm x 10mm x 3.8mm
- DC Resistance Max: 0.213ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Reel Quantity: 250
- Self Resonant Frequency Min: 10MHz
