COILCRAFT - MSS1048-224KLC - Power Inductor (SMD), 220 µH, 1.18 A, Shielded, 670 mA, MSS1048
- Inductance: 220µH
- RMS Current (Irms): 1.18A
- Inductor Construction: Shielded
- Saturation Current (Isat): 670mA
- Product Range: MSS1048 Series
- Power Inductor Case: 10.2mm x 10mm x 4.8mm
- DC Resistance Max: 0.394ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 4.5MHz
