NEUTRIK - NC3FRX-BAG - XLR Connector, 3 Contacts, Socket, Cable Mount, Silver Plated Contacts, Metal Body, RX
- No. of Contacts: 3Contacts
- Gender: Socket
- Connector Mounting: Cable Mount
- Contact Plating: Silver Plated Contacts
- Connector Body Material: Metal Body
- Product Range: RX Series
- SVHC: No SVHC (27-Jun-2018)
- Cable Diameter Max: 8mm
- Cable Diameter Min: 3.5mm
- Colour: Black
- Connector Colour: Black
- Contact Resistance: 3mohm
- Contact Termination: Solder
- Current Rating: 16A
- External Depth: 69.3mm
- Flammability Rating: UL94HB
- Insertion Force: 20N
- Insulation Resistance: 2Gohm
- Material: Black Cr
- Mechanical Life: 1000 cycles
- No. of Mating Cycles: 1000
- Operating Temperature Max: 80°C
- Operating Temperature Min: -30°C
- Termination Method: Solder
- Voltage Rating VAC: 50V
- Wire Area Size Max: 2.5mm²
- Wire Size AWG Max: 14AWG
- XLR Capacitance: 4pF
