OJE-SS-112HMF,F000 Relay, SPST-NO, 250VAC, 30Vdc, 10A OEG - Te Connectivity

OEG - TE CONNECTIVITYSKU:4-1419128-4 Bestelcode:1891668

Prijs:
Actie prijs€3,24

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (145 units)

Documenten en downloads

Omschrijving

OEG - TE CONNECTIVITY - 4-1419128-4 - General Purpose Relay, OJE Series, Power, Non Latching, SPST-NO, 12 VDC, 10 A

  • Contact Configuration: SPST-NO
  • Coil Voltage: 12VDC
  • Contact Current: 10A
  • Product Range: OJE Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 30VDC
  • Contact Material: Silver
  • Coil Resistance: 320ohm
  • SVHC: No SVHC (15-Jan-2018)
  • Approvals & Standards: VDE
  • Coil Voltage VDC Nom: 12V
  • Contact Current Max: 10A
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Nom: 30V
  • External Depth: 18.2mm
  • External Height: 14.6mm
  • External Width: 10.2mm
  • Relay Type: Power
