TE CONNECTIVITY - 1721441-5 - General Purpose Relay, PCN Series, Power, Non Latching, SPST-NO, 12 VDC, 5 A
- Contact Configuration: SPST-NO
- Coil Voltage: 12VDC
- Contact Current: 5A
- Product Range: PCN Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: 30VDC
- Contact Material: Silver Nickel
- Coil Resistance: 1.2kohm
- SVHC: No SVHC (27-Jun-2018)
- Coil Voltage VDC Nom: 12V
- Contact Current Max: 5A
- Contact Voltage AC Nom: 250V
- Contact Voltage DC Nom: 30V
- External Depth: 20mm
- External Height: 12.5mm
- External Width: 5mm
- Nom Operating Power: 120mW
- Relay Type: Power
