Omschrijving
DOLD - PH 9260.91 AC 24 - 240V AC 50A - Solid State Relay, 50 A, 240 VAC, Panel Mount, Screw, Zero Crossing
- Contact Configuration: -
- Load Current: 50A
- Operating Voltage Max: 240VAC
- Relay Mounting: Panel
- Relay Terminals: Screw
- Switching Mode: Zero Crossing
- Operating Voltage Min: 24VAC
- Control Voltage Min: 4VDC
- Control Voltage Max: 32VDC
- Product Range: PH 9260 Series
- SVHC: No SVHC (15-Jan-2018)
- Control Voltage DC Max: 32VDC
- Control Voltage DC Min: 4VDC
- Control Voltage Range: 4V DC to 32V DC
- Control Voltage Type: DC
- External Depth: 32mm
- External Length / Height: 45mm
- External Width: 58mm
- Height: 45mm
- Isolation Voltage: 4kV
- Load Current Min: 20mA
- Load Current RMS Max: 50A
- Operating Temperature Max: 80°C
- Operating Temperature Min: -20°C
- Operating Voltage Range: 24V AC to 240V AC
- Output Type: Thyristor
- RMS Load Voltage Max: 240V
- RMS Load Voltage Min: 24V
- Single Cycle Surge Current: 600A
- Surge Current: 50A
- Type: 0056652
