MICROCHIP - PIC16F785-I/SS - 8 Bit MCU, Flash, PIC16 Family PIC16F7XX Series Microcontrollers, 20 MHz, 3.5 KB, 128 Byte, 20 Pins
- Product Range: PIC16 Family PIC16F7XX Series Microcontrollers
- CPU Speed: 20MHz
- Program Memory Size: 3.5KB
- RAM Memory Size: 128Byte
- No. of Pins: 20Pins
- MCU Case Style: SSOP
- No. of I/O's: 18I/O's
- Embedded Interface Type: -
- Supply Voltage Min: 2V
- Supply Voltage Max: 5.5V
- MCU Family: PIC16
- MCU Series: PIC16F7xx
- Automotive Qualification Standard: AEC-Q100
- MSL: MSL 1 - Unlimited
- SVHC: No SVHC (27-Jun-2018)
- Controller Family/Series: PIC16F
- EEPROM Memory Size: 256Byte
- Flash Memory Size: 3.5KB
- IC Generic Number: 16F785
- IC Temperature Range: Industrial
- Logic Function Number: 16F785
- MPU Core Size: 8bit
- Memory Type: Flash
- Microprocessor/Controller Features: 2 Operational Amplifiers, 2 Comparators, PWM (2-phase), 2 x 8-bit timer, 1 x 16-bit timer, 256bytes EEPROM, 128bytes SRAM
- No. of ADC Inputs: 14
- No. of Bits: 8bit
- No. of PWM Channels: 2
- No. of Timers: 3
- Number of bits in ADC: 10
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Oscillator Type: External, Internal
