R125462001 RF Coaxial, Sma, Straight Jack, 50ohm RADIALL

RADIALLSKU:R125462001 Bestelcode:4194792

Prijs:
Actie prijs€36,45

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (199 units)

Documenten en downloads

Omschrijving

RADIALL - R125462001 - RF / Coaxial Connector, SMA Coaxial, Straight Flanged Jack, 50 ohm, Beryllium Copper

  • Connector Type: SMA Coaxial
  • Connector Body Style: Straight Flanged Jack
  • Coaxial Termination: -
  • Impedance: 50ohm
  • Coaxial Cable Types: -
  • Contact Material: Beryllium Copper
  • Contact Plating: Gold Plated Contacts
  • Frequency Max: 18GHz
  • Connector Mounting: Panel Mount
  • Product Range: -
  • SVHC: No SVHC (15-Jan-2018)
  • Body Plating: Gold
  • Connector Mounting Orientation: Panel
  • Insulation Resistance: 5000Mohm
  • Material: Stainless Steel
  • No. of Mating Cycles: 500
  • Operating Frequency Max: 18kHz
  • Operating Temperature Max: 165°C
  • Operating Temperature Min: -65°C
  • Voltage Rating VAC: 500V
  • Withstand Voltage: 1000V
