R13-548A-05-BB SWITCH, PUSH BUTTON, SPST, MOM MULTICOMP PRO

MULTICOMP PROSKU:R13-548A-05-BB Bestelcode:1634679

Prijs:
Actie prijs€3,64

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (674 units)

Documenten en downloads

Omschrijving

MULTICOMP PRO - R13-548A-05-BB - Pushbutton Switch, 12.1 mm, SPST, (On)-Off, Round Raised, Black

  • Switch Operation: (On)-Off
  • Contact Configuration: SPST
  • Contact Voltage AC Nom: 125V
  • Contact Voltage DC Nom: 14V
  • Contact Current Max: 3A
  • Switch Terminals: Solder Lug
  • Product Range: -
  • Actuation Type: Round
  • Actuator / Cap Colour: Black
  • Bezel Diameter: 14mm
  • Colour: Black
  • Contact Current AC: 1.5A
  • Contact Current AC Max: 6A
  • Contact Current DC: 3A
  • Contact Current DC Max: 6A
  • Contact Resistance: 50mohm
  • Contact Voltage VAC: 125V
  • Contact Voltage VDC: 14V
  • Height: 16mm
  • Illumination Colour: Non-illuminated
  • Insulation Resistance: 500Mohm
  • Insulation Resistance Voltage: 500VDC
  • Operating Temperature Max: 65°C
  • Operating Temperature Min: -20°C
  • Panel Cutout Diameter: 12.1mm
  • Panel Thickness Max: 3mm
  • Pushbutton Actuator Style: Raised Round
  • Pushbutton Switch Type: Standard
  • Shaft Diameter: 8.2mm
  • Shaft Length: 6mm
  • Switch Mounting: Panel
