RF3002A/HFS30 Float Switch, R/A COMUS (ASSEMTECH)

COMUS (ASSEMTECH)SKU:RF3002A/HFS30 Bestelcode:730191

Prijs:
Actie prijs€105,10

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (8 units)

Documenten en downloads

Omschrijving

COMUS (ASSEMTECH) - RF3002A/HFS30 - Float Switch, RF3002A Series, Vertical, SPST-NC, Stainless Steel, 50 VA

  • Operating Pressure Max: 10bar
  • Sensor Body Material: Stainless Steel
  • Output Current: 500mA
  • Product Range: -
  • SVHC: No SVHC (27-Jun-2018)
  • Body Material: Stainless Steel
  • Contact Configuration: SPST
  • Contact Current AC Max: 1A
  • Contact Voltage AC Max: 240V
  • External Length / Height: 57mm
  • Fixing Hole Diameter: 10mm
  • Float Diameter: 28m
  • Lead Length: 0.3m
  • Material: Stainless Steel 304
  • Operating Pressure Range: 0bar to 10bar
  • Operating Temperature Max: 120°C
  • Operating Temperature Min: -10°C
  • Power Rating: 50W
  • Specific Gravity of Liquid Min: 0.75
  • Switching Voltage AC / DC Max: 200VDC
  • Switching Voltage AC / DC Min: 240VAC
