RFH34024WG Relay, SPST, 250VAC, 16A Te Connectivity

TE CONNECTIVITYSKU:6-1415520-1 Bestelcode:9659595

Prijs:
Actie prijs€7,87

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (391 units)

Documenten en downloads

Omschrijving

TE CONNECTIVITY - 6-1415520-1 - General Purpose Relay, RF Series, Power, Non Latching, SPST, 24 VDC, 16 A

  • Contact Configuration: SPST
  • Coil Voltage: 24VDC
  • Contact Current: 16A
  • Product Range: RF Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: -
  • Contact Material: Silver Nickel
  • Coil Resistance: 1.44kohm
  • SVHC: No SVHC (15-Jan-2018)
  • Approval Bodies: VDE
  • Approval Category: UL Recognised
  • Coil Voltage VDC Nom: 24V
  • Contact Current AC Max: 16A
  • Contact Current Max: 16A
  • Contact Current Min: 500mA
  • Contact Voltage AC Max: 400V
  • Contact Voltage AC Nom: 240V
  • Current Rating: 16A
  • DC Coil Power: 400mW
  • Dielectric Voltage Coil to Contact: 4000VAC
  • Dielectric Voltage Contact to Contact: 1500VAC
  • External Depth: 13.2mm
  • External Height: 16mm
  • External Length / Height: 16mm
  • External Width: 29mm
  • Flammability Rating: UL94V-0
  • Must Actuate Voltage: 16.8V
  • Nom Operating Power: 400mW
  • Operating Temperature Max: 105°C
  • Operating Temperature Min: -40°C
  • Operating Time: 10ms
  • Relay Type: Power
  • Release Time: 5ms
