RTB14012 Relay, SPDT, 250VAC, 12A SCHRACK - Te Connectivity

SCHRACK - TE CONNECTIVITYSKU:RTB14012 Bestelcode:1175013

Prijs:
Actie prijs€6,29

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (113676 units)

Documenten en downloads

Omschrijving

SCHRACK - TE CONNECTIVITY - 1-1393238-5 - General Purpose Relay, Power PCB Relay RT1 Series, Power, Non Latching, SPDT, 12 VDC, 12 A

  • Contact Configuration: SPDT
  • Coil Voltage: 12VDC
  • Contact Current: 12A
  • Product Range: RT1 Series
  • Relay Mounting: Through Hole
  • Coil Type: DC
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: -
  • Contact Material: Silver Nickel
  • Coil Resistance: 360ohm
  • SVHC: No SVHC (15-Jan-2018)
  • Approval Bodies: BEAB, CSA, KEMA-KEUR, SEMKO, SETI, VDE
  • Approval Category: UL Recognised
  • Approvals & Standards: CSA, UL, VDE
  • Coil Operating Lower Percent Limit: 70%
  • Coil Operating Upper Percent Limit: 175%
  • Coil Voltage VDC Nom: 12V
  • Contact Current AC Max: 12A
  • Contact Current DC Max: 12A
  • Contact Current Max: 12A
  • Contact Voltage AC Max: 250V
  • Contact Voltage AC Nom: 240V
  • Contact Voltage DC Max: 30V
  • DC Coil Power: 400mW
  • Dielectric Voltage Coil to Contact: 5kV
  • Dielectric Voltage Contact to Contact: 1kV
  • External Depth: 15.7mm
  • External Height: 29mm
  • External Length / Height: 29mm
  • External Width: 12.7mm
  • Lead Spacing: 3.5mm
  • Nom Operating Power: 400mW
  • Operating Temperature Max: 70°C
