RTE24012 Relay, DPDT, 250VAC, 8A SCHRACK - Te Connectivity

SCHRACK - TE CONNECTIVITYSKU:RTE24012 Bestelcode:1175020

Prijs:
Actie prijs€6,16

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (9012 units)

Documenten en downloads

Omschrijving

SCHRACK - TE CONNECTIVITY - RTE24012 - General Purpose Relay, RT2 Series, 8 A, 12 Vdc, Power, Non Latching, DPDT

  • Contact Configuration: DPDT
  • Coil Voltage: 12VDC
  • Contact Current: 8A
  • Product Range: RT2 Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: -
  • Contact Material: Silver Nickel
  • Coil Resistance: 360ohm
  • SVHC: No SVHC (15-Jan-2019)
  • Approval Bodies: BEAB, CSA, OVE, SEMKO, UL, VDE
  • Approvals & Standards: CSA, UL, VDE
  • Coil Current: 33.3mA
  • Coil Operating Lower Percent Limit: 70%
  • Coil Operating Upper Percent Limit: 175%
  • Coil Voltage VDC Nom: 12V
  • Contact Current AC Max: 8A
  • Contact Current Max: 8A
  • Contact Voltage AC Max: 250V
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Nom: 30V
  • DC Coil Power: 400mW
  • External Depth: 15.7mm
  • External Height: 29mm
  • External Length / Height: 29mm
  • External Width: 12.7mm
  • Lead Spacing: 5.0mm
  • Nom Operating Power: 400mW
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -40°C
  • Operating Time: 8ms
  • Relay Type: Power - General Purpose
  • Release Time: 6ms
  • Row Pitch: 7.5mm
