RTE24012F Relay, DPDT, 250VAC, 24Vdc, 3a Potter&BRUMFIELD - Te Connectivity

POTTER&BRUMFIELD - TE CONNECTIVITYSKU:3-1393237-1 Bestelcode:1891963

Prijs:
Actie prijs€8,23

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (3792 units)

Documenten en downloads

Omschrijving

POTTER&BRUMFIELD - TE CONNECTIVITY - 3-1393237-1 - General Purpose Relay, RT2 Series, 8 A, 12 Vdc, Power, Non Latching, DPDT

  • Contact Configuration: DPDT
  • Coil Voltage: 12VDC
  • Contact Current: 8A
  • Product Range: RT2 Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 24VDC
  • Contact Material: Silver Nickel
  • Coil Resistance: 360ohm
  • SVHC: No SVHC (15-Jan-2018)
  • Approvals & Standards: CSA, UL, VDE
  • Coil Current: 33.3mA
  • Coil Voltage VDC Nom: 12V
  • Contact Current Max: 8A
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Nom: 30V
  • External Depth: 29mm
  • External Height: 15.7mm
  • External Width: 12.7mm
  • Nom Operating Power: 400mW
  • Relay Type: Power - General Purpose
