RTE24048 Relay, DPDT, 250VAC, 8A SCHRACK - Te Connectivity

SCHRACK - TE CONNECTIVITYSKU:RTE24048 Bestelcode:1175022

Prijs:
Actie prijs€5,30

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (93 units)

Documenten en downloads

Omschrijving

SCHRACK - TE CONNECTIVITY - 1-1393243-1 - General Purpose Relay, RT2 Series, 8 A, 48 Vdc, Power, Non Latching, DPDT

  • Contact Configuration: DPDT
  • Coil Voltage: 48VDC
  • Contact Current: 8A
  • Product Range: RT2 Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: -
  • Contact Material: Silver Nickel
  • Coil Resistance: 5.76kohm
  • SVHC: No SVHC (15-Jan-2018)
  • Approval Bodies: CSA, VDE
  • Approval Category: UL Recognised
  • Approvals & Standards: CSA, UL, VDE
  • Coil Current: 8.3mA
  • Coil Operating Lower Percent Limit: 70%
  • Coil Operating Upper Percent Limit: 175%
  • Coil Voltage VDC Nom: 48V
  • Contact Current AC Max: 8A
  • Contact Current DC Max: 10A
  • Contact Current Max: 8A
  • Contact Voltage AC Max: 250V
  • Contact Voltage AC Nom: 277V
  • Contact Voltage DC Max: 30V
  • Contact Voltage DC Nom: 30V
  • DC Coil Power: 400mW
  • Dielectric Voltage Coil to Contact: 5kV
  • Dielectric Voltage Contact to Contact: 1kV
  • External Depth: 15.7mm
  • External Height: 29mm
  • External Length / Height: 29mm
  • External Width: 12.7mm
  • Lead Spacing: 5mm
  • Must Actuate Voltage: 33.6V
  • Weight: 13g
