Omschrijving
IDEC - RY2S-UDC24V - General Purpose Relay, RY Series, Power, Non Latching, DPDT, 24 VDC, 3 A
- Contact Configuration: DPDT
- Coil Voltage: 24VDC
- Contact Current: 3A
- Product Range: RY Series
- Relay Mounting: Socket
- Coil Type: Non Latching
- Contact Voltage VAC: 240VAC
- Relay Terminals: Plug In
- Contact Voltage VDC: 30VDC
- Contact Material: Silver
- Coil Resistance: 750ohm
- SVHC: No SVHC (15-Jan-2019)
- Approvals & Standards: CSA, UL
- Coil Voltage VDC Nom: 24V
- Contact Current Max: 5A
- Contact Voltage AC Nom: 240V
- Contact Voltage DC Nom: 100V
- External Depth: 27.6mm
- External Height: 35.6mm
- External Length / Height: 35.6mm
- External Width: 14mm
- Relay Type: Power - General Purpose
