RZ3A60D40 SSR, 40A, 600VAC Carlo GAVAZZI

CARLO GAVAZZISKU:RZ3A60D40 Bestelcode:5540513

Prijs:
Actie prijs€270,62

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (26 units)

Documenten en downloads

Omschrijving

CARLO GAVAZZI - RZ3A60D40 - Solid State Relay, 3PST-NO, 40 A, 660 VAC, Panel Mount, Screw, Zero Crossing

  • Contact Configuration: 3PST-NO
  • Load Current: 40A
  • Operating Voltage Max: 660VAC
  • Relay Mounting: Panel
  • Relay Terminals: Screw
  • Switching Mode: Zero Crossing
  • Operating Voltage Min: 42VAC
  • Control Voltage Min: 4VDC
  • Control Voltage Max: 32VDC
  • Product Range: RZ3A Series
  • SVHC: No SVHC (15-Jan-2019)
  • Blocking voltage: 1200V
  • Control Current Typ: 23mA
  • Control Voltage DC Max: 32VDC
  • Control Voltage DC Min: 4VDC
  • Control Voltage Pickup: 3.8VDC
  • Control Voltage Range: 4V DC to 32V DC
  • Control Voltage Type: DC
  • External Depth: 41mm
  • External Length / Height: 103mm
  • External Width: 73.5mm
  • Fixing Centres LxW: 92 x 47.6 mm
  • Input Voltage Max: 660VAC
  • Input Voltage Min: 42VAC
  • Isolation Voltage: 4kV
  • Leakage Current: 3mA
  • Load Current Min: 150mA
  • Load Current RMS Max: 40A
  • No. of Phases: Three Phase
  • Operating Frequency Max: 65Hz
  • Operating Frequency Min: 45Hz
  • Operating Temperature Max: 80°C
  • Operating Temperature Min: -30°C
  • Operating Voltage Range: 42V AC to 660V AC
  • Output Type: Triac
  • Surge Current: 60A
