Omschrijving
MULTICOMP PRO - S1D+ - Standard Recovery Diode, 200 V, 1 A, Single, 1.1 V, 30 A
- Repetitive Reverse Voltage Vrrm Max: 200V
- Forward Current If(AV): 1A
- Diode Configuration: Single
- Forward Voltage VF Max: 1.1V
- Reverse Recovery Time trr Max: -
- Forward Surge Current Ifsm Max: 30A
- Operating Temperature Max: 150°C
- Diode Case Style: DO-214AC
- No. of Pins: 2Pins
- Product Range: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- Alternate Case Style: DO-214AC
- Av Current If: 1A
- Current If @ Vf: 1A
- Current Ifsm: 30A
- Current Ir Max: 5µA
- Current Temperature: 25°C
- Diode Polarity: Cathode
- Diode Type: Standard Recovery
- External Depth: 1.58mm
- External Length / Height: 2.61mm
- External Width: 4.75mm
- Forward Current If Max: 1mA
- Junction Temperature Tj Max: 150°C
- Junction Temperature Tj Min: -55°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +150°C
- Peak Forward Current: 1A
- RMS Input Voltage: 140V
- Reverse Recovery Time trr Typ: 1.8µs
- SMD Marking: S1D
- Termination Type: Surface Mount Device
- Weight: 0.064g
