S6-1A6 PHOTOSWITCH, Reflex Datasensor

DATASENSORSKU:S6-1A6 Bestelcode:213240

Prijs:
Actie prijs€225,09

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (16 units)

Documenten en downloads

Omschrijving

TE CONNECTIVITY - 2132403-5 - 2X5 SFP+ W/ SPRINGS, 4 LP SN

  • Sensing Range Max: 6m
  • Sensing Method: Retroreflective
  • Sensor Output: Relay
  • Product Range: S6 Series
  • Connection Method: Cable
  • Supply Voltage DC Min: 10V
  • Supply Voltage DC Max: 30V
  • SVHC: No SVHC (15-Jan-2018)
  • Contact Voltage AC Max: 275VAC
  • Contact Voltage DC Max: 30VDC
  • External Depth: 50mm
  • External Length / Height: 50mm
  • External Width: 18mm
  • Frequency Response Max: 500Hz
  • IP / NEMA Rating: IP65
  • Lead Length: 2m
  • Operating Temperature Max: 55°C
  • Operating Temperature Min: -15°C
  • Output Current Max: 3A
  • Power Consumption: 35mW
  • Response Time: 30ms
  • Sensing Distance Max: 6m
  • Sensing Distance Min: 100mm
  • Sensing Range: 100mm to 6m
  • Sensor Input: Optical
  • Supply Voltage AC Max: 264V
  • Supply Voltage AC Min: 15V
  • Supply Voltage Range DC: 10V to 30V
  • Switching Current AC Max: 3A
  • Switching Current DC Max: 3A
