BOURNS - SDR0604-101KL - Power Inductor (SMD), 100 µH, 520 mA, Unshielded, 680 mA, SDR0604, 5.8mm x 5.8mm x 4.8mm
- Inductance: 100µH
- RMS Current (Irms): 520mA
- Inductor Construction: Unshielded
- Saturation Current (Isat): 680mA
- Product Range: SDR0604 Series
- Power Inductor Case: 5.8mm x 5.8mm x 4.8mm
- DC Resistance Max: 0.7ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2018)
- External Depth: 5.8mm
- External Length / Height: 4.8mm
- External Width: 5.8mm
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Q Factor: 20
- Q Test Frequency: 796kHz
- Resonant Frequency: 9MHz
- Self Resonant Frequency Min: 9MHz
- Test Frequency: 0.796MHz
