SEMIKRON - SKCH40/08 - Thyristor Bridge Rectifier Module, Single Phase, 46 A, 800 V
- SCR Module Type: Bridge Rectifier, Single Phase - SCR
- Peak Repetitive Off-State Voltage, Vdrm: 800V
- Gate Trigger Current Max, Igt: 150mA
- Current It av: 46A
- On State RMS Current IT(rms): -
- Peak Non Rep Surge Current Itsm 50Hz: 470A
- Holding Current Max Ih: 200mA
- Gate Trigger Voltage Max Vgt: 2.3V
- Operating Temperature Max: 125°C
- Product Range: -
- SVHC: No SVHC (15-Jun-2015)
- Current Itsm: 470A
- Current Temperature: 85°C
- Module Configuration: Single Phase Bridge Rectifier + Protection Diode
- No. of Pins: 6Pins
- Operating Temperature Min: -40°C
- Operating Temperature Range: -40°C to +125°C
- Rate of Voltage Change dv / dt: 500V/µs
- Repetitive Reverse Voltage Vrrm Max: 800V
- Termination Type: Screw
- Thyristor Case Style: Module
- Thyristor Type: Thyristor / Diode Module
