VISHAY - SMCJ15A-E3/57T - TVS Diode, TRANSZORB SMCJ, Unidirectional, 15 V, 24.4 V, DO-214AB (SMC), 2 Pins
- Product Range: TRANSZORB SMCJ Series
- TVS Polarity: Unidirectional
- Reverse Stand-Off Voltage Vrwm: 15V
- Clamping Voltage Vc Max: 24.4V
- Diode Case Style: DO-214AB
- No. of Pins: 2Pins
- Breakdown Voltage Min: 16.7V
- Breakdown Voltage Max: 18.5V
- Peak Pulse Power Dissipation: 1.5kW
- Automotive Qualification Standard: -
- SVHC: Lead (15-Jan-2019)
- Alternate Case Style: DO-214AB
- Breakdown Voltage: 16.7V
- Breakdown Voltage Range: 16.7V to 18.5V
- Breakover Voltage Min: 16.7V
- Diode Type: Unidirectional TVS
- External Depth: 3.94mm
- External Length / Height: 2.44mm
- External Width: 4.57mm
- Operating Temperature Max: 150°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +150°C
- Peak Pulse Current Ippm: 61.5A
- Power Dissipation Pd: 6.5W
- Reverse Leakage Current Max: 1µA
- SMD Marking: GEM
- Stand-off Voltage: 15V
- Test Current: 1mA
- Uni / Bi Directional Polarity: Unidirectional
