BOURNS - SRP1238A-R15Y - Power Inductor (SMD), 150 nH, 41 A, Shielded, 75 A, SRP1238A, 13.5mm x 12.5mm x 3.3mm
- Inductance: 150nH
- RMS Current (Irms): 41A
- Inductor Construction: Shielded
- Saturation Current (Isat): 75A
- Product Range: SRP1238A Series
- Power Inductor Case: 13.5mm x 12.5mm x 3.3mm
- DC Resistance Max: 480µohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (15-Jan-2018)
- Automotive Qualification Standard: AEC-Q200
