Omschrijving
BOURNS - SRP1250-2R2M - Power Inductor (SMD), 2.2 µH, 20 A, Shielded, 32 A, SRP1250, 13.9mm x 13.5mm x 5.9mm
- Inductance: 2.2µH
- RMS Current (Irms): 20A
- Inductor Construction: Shielded
- Saturation Current (Isat): 32A
- Product Range: SRP1250 Series
- Power Inductor Case: 13.9mm x 13.5mm x 5.9mm
- DC Resistance Max: 0.0055ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2018)
- External Depth: 13.5mm
- External Length / Height: 5.9mm
- External Width: 13.9mm
- No. of Pins: 2Pins
- Operating Temperature Max: 155°C
- Operating Temperature Min: -55°C
- Test Frequency: 100kHz
