Omschrijving
BOURNS - SRP1250-4R7M - Power Inductor (SMD), 4.7 µH, 12 A, Shielded, 27 A, 13.9mm x 13.5mm x 5.9mm
- Inductance: 4.7µH
- RMS Current (Irms): 12A
- Inductor Construction: Shielded
- Saturation Current (Isat): 27A
- Product Range: -
- Power Inductor Case: 13.9mm x 13.5mm x 5.9mm
- DC Resistance Max: 0.015ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (07-Jul-2017)
- External Depth: 13.5mm
- External Length / Height: 5.9mm
- External Width: 13.9mm
- No. of Pins: 2Pins
- Operating Temperature Max: 155°C
- Operating Temperature Min: -55°C
- Test Frequency: 100kHz
