BOURNS - SRR1240-2R4Y - Power Inductor (SMD), 2.4 µH, 8 A, Shielded, 7.8 A, SRR1240
- Inductance: 2.4µH
- RMS Current (Irms): 8A
- Inductor Construction: Shielded
- Saturation Current (Isat): 7.8A
- Product Range: SRR1240 Series
- Power Inductor Case: 12.5mm x 12.5mm x 4mm
- DC Resistance Max: 0.0115ohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (15-Jan-2018)
- No. of Pins: 2Pins
- Q Factor: 10
- Q Test Frequency: 7.96MHz
- Self Resonant Frequency Min: 54MHz
